Scope of application: hospital, bank data center, wall-mounted home, enterprise energy storage backup power supply, wind complementary system, office, military, base station and other uninterrupted energy storage power supply.
Basic Parameters
Batteries materials: Lithium iron phosphate
Series parallel mode (S series, P parallel): 8S1P
Nominal voltage: 25.6V
Nominal capacity: 100Ah
Size(mm): 410*370*155
Weight: 24.7kg
Color: Optional
Output port mode: terminal
Parallel support: Parallel terminals are supported
Charging way: CC/CP/VP
Charging current: 0.2C(standard)
Maximum charging current: Max 0.5C @25℃
Charge cut-off voltage: 28.8V/CELL
Discharge way: CC/CP/VP
Discharge current: 0.5C
Maximum discharge current: Max 1C @25℃
Discharge cut-off voltage: 22.4V
According to: LCD
Communication interface: RS485/RS232/CAN
Charging operating temperature: charging: 0~+50℃
Discharge operating temperature: discharge: -20~+55℃
The quality assurance period: 36 months
