Applicable scope: hospital, bank data center, base frame type home, enterprise energy storage backup power supply, wind complementary system, office, military, base station and other uninterrupted energy storage power supply.
Basic Parameters
Batteries materials: Lithium iron phosphate
Series parallel mode (S series, P parallel): 8S1P
Nominal voltage: 25.6v
Nominal capacity: 100Ah
Size(mm): 475*450(492)*133
Weight: 36kg
Color: Optional
Parallel support: Parallel terminals are supported
Output port mode: terminal
Charging way: CC/CP/VP
Charging current: 0.2C(standard )
Maximum charging current: Max0.5C @25C
Charge cut-off voltage: 29.2V/CELL
Discharge way: CC/CP/VP
Discharge current: 0.5C
Maximum discharge current: Max1C @25℃
Discharge cut-off voltage: 22.4V
Charging operating temperature: charging: 0~+50℃
Discharge operating temperature: discharge 20~+55℃
The quality assurance period: 36 months
