Applicable scope: hospital, bank data center, base frame type home, enterprise energy storage backup power supply, wind complementary system, office, military, base station and other uninterrupted energy storage power supply.
Basic Parameters
Batteries materials: Lithium iron phosphate
Series parallel mode (S series, P parallel): 16S1P
Nominal voltage: 51.2V
Nominal capacity: 100Ah
Size ( mm): 860*515*150
Weight: 59.9kg
Color: Optional
Output port mode: AC220V
Socket Charging way: Mains/PV
Charging current: 0.2C(standard )
Maximum charging current: Max0.5C @25℃
Charge cut-off voltage: 58.4V/CELL
Discharge way: CP/VP
Discharge current: 0.5C
Maximum discharge current: Max1C@25℃
Discharge cut-off voltage: 44.8V
According to: LCD
Communication interface: RS485/RS232/CAN
Charging operating temperature: charging: 0~+50℃
Discharge operating temperature: discharge: -20~+55℃
Built-in inverter parameters: 5KW
The quality assurance period: 36 months
