Applicable scope: hospital, bank data center, base frame type home, enterprise energy storage backup power supply, wind complementary system, office, military, base station and other uninterrupted energy storage power supply.
Basic Parameters
Batteries materials: Lithium iron phosphate
Series parallel mode (S series, P parallel): 16S1P
Nominal voltage: 51.2V
Nominal capacity: 200Ah
Size(mm): 588*430*195(monomer)
Weight: 48kg ( Battery)
Color: Optional
Charging way: CP/VP
Charging current: 0.2C(standard)
Maximum charging current: Max0.5C @25C
Charge cut-off voltage: 58.4V
Discharge way: CP/VP
Discharge current: 1C
Maximum discharge current: Max1C @25℃
Discharge cut-off voltage: 44.8V
Communication interface: RS485/RS232/CAN
Charging operating temperature: charging: 0~+50℃
Discharge operating temperature: discharge: -20~+55℃
Inverter: 3.5KW/5.5KW
The quality assurance period: 36 months
