ZEM’s 80V lithium-ion batteries are designed to accommodate various ground support equipment through its modular design and integral battery management system. As a vehicle that can operate in a variety of environments, with locations around the world, the battery has a temperature range from - 30°.
PRODUCT SPECIFICATIONS
| ELECTRICAL SPECIFICATIONS | |
| Nominal capacity | 460 |
| Open circuit voltage | 83.2V |
| Voltage | 80V |
| Self-discharge | <3% per month |
| Cycle life | >3000 (at 10C discharge, 100% DoD) |
| EqPb (Equals Lead acid battery) | 575 |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (LxWxH) | L1025*W995*H625MM |
| Weight | 1635KG |
| Case material | Commercial Grade Steel |
| Ingress protection | IP65 |
| Cell type / Chemistry | Diamond - LiFePO4 |
| Group mode | 26S2P |
| CHARGE & DISCHARGE SPECIFICATIONS | |
| Charge method | CCCV |
| Charge voltage | 76.8V - 96V |
| Maximum continuous charging current | 400A |
| Continuous discharge current | 600A |
| Discharge current continuous | 40A |
| Discharge pulse current | 600A (1 sec)/ 800A (1 sec)/1200A (1 sec) |
| Working Voltage Range | 76.8-89.6V |
| TEMPERATURE SPECIFICATIONS | |
| Charge temperature | 0°C to 50°C / 32°F to 131°F |
| Discharge temperature | -20°C to 55°C / -4°F to 131°F |
| Storage temperature | 0°C to 40°C / -4°F to 113°F |
| COMPLIANCE SPECIFICATIONS | |
| Certifications | CE, UN 38.3, UL2580,IEC, CB, ISO9001 |
| Shipping classification | UN 3480 |
| COMMUNICATION METHOD | |
| Vehicle communication mode | CAN |
| Display communication method | RS485 |
PERFORMANCE
Low maintenance
Fast charging
Safest lithium technology
High discharge currents
High capacity
Low Temperature and High Efficiency
