Discover ZEM GSE Lithium Battery’s diverse range for aviation support. Our robust lineup includes Start Power, Tug Batteries, Backup Solutions, and Specialty Applications. GSE lithium-ion Battery powers your operations. View GSE Lithium battery. Ready to revolutionize your business with lithium-ion? Request a free ROI calculation and find out how much you could be saving when you switch your fleet to lithium-ion.
PRODUCT SPECIFICATIONS
| ELECTRICAL SPECIFICATIONS | |
| Nominal capacity | 280 |
| Open circuit voltage | 83.2V |
| Voltage | 80V |
| Cycle life | >3000 (at 10C discharge, 100% DoD) |
| EqPb (Equals Lead acid battery) | 350 |
| Self-discharge | <3% per mont |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (LxWxH) | L970*W265*H549.5MM |
| Weight | 284KG |
| Case material | Commercial Grade Steel |
| Ingress protection | IP67 |
| Cell type / Chemistry | Diamond - LiFePO4 |
| Group mode | 25S1P |
| CHARGE & DISCHARGE SPECIFICATIONS | |
| Charge method | CCCV |
| Charge voltage | 76.8V - 96V |
| Maximum continuous charging current | 400A |
| Continuous discharge current | 600A |
| Discharge current continuous | 40A |
| Discharge pulse current | 600A (1 sec)/ 800A (1 sec)/1200A (1 sec) |
| Working Voltage Range | 76.8-89.6V |
| TEMPERATURE SPECIFICATIONS | |
| Charge temperature | 0°C to 50°C / 32°F to 131°F |
| Discharge temperature | -20°C to 55°C / -4°F to 131°F |
| Storage temperature | 0°C to 40°C / -4°F to 113°F |
| COMPLIANCE SPECIFICATIONS | |
| Certifications | CE, UN 38.3, UL2580,IEC, CB, ISO9001 |
| Shipping classification | UN 3480 |
| COMMUNICATION METHOD | |
| Vehicle communication mode | CAN |
| Display communication method | RS485 |
PERFORMANCE
Low maintenance
Fast charging
Safest lithium technology
High discharge currents
High capacity
Low Temperature and High Efficiency
