Power Your Electric Aircraft Tow Tractor with GSE Lithium Battery Solutions from ZEM Create a cleaner, greener environment for your airport, ground handling company, or fixed base operation with ZEMBATT. Our current product line already features GSE lithium battery solutions for industry-leading electric aircraft tow tractor manufacturers to meet your operational needs with unmatched efficiency. Browse our entire catalog today. If you have any questions, please feel free to contact us. We are happy to assist you.
PRODUCT SPECIFICATIONS
| ELECTRICAL SPECIFICATIONS | |
| Nominal capacity | 615 |
| Open circuit voltage | 83.2V |
| Voltage | 80V |
| Self-discharge | <3% per month |
| Cycle life | >3000 (at 10C discharge, 100% DoD) |
| EqPb (Equals Lead acid battery) | 780 |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (LxWxH) | L1025*W995*H625MM |
| Weight | 1120KG |
| Case material | Commercial Grade Steel |
| Ingress protection | IP65 |
| Cell type / Chemistry | Diamond - LiFePO4 |
| Group mode | 26S3P |
| CHARGE & DISCHARGE SPECIFICATIONS | |
| Charge method | CCCV |
| Charge voltage | 76.8V - 96V |
| Maximum continuous charging current | 400A |
| Continuous discharge current | 600A |
| Discharge current continuous | 40A |
| Discharge pulse current | 600A (1 sec)/ 800A (1 sec)/1200A (1 sec) |
| Working Voltage Range | 76.8-89.6V |
| TEMPERATURE SPECIFICATIONS | |
| Charge temperature | 0°C to 50°C / 32°F to 131°F |
| Discharge temperature | -20°C to 55°C / -4°F to 131°F |
| Storage temperature | 0°C to 40°C / -4°F to 113°F |
| COMPLIANCE SPECIFICATIONS | |
| Certifications | CE, UN 38.3, UL2580,IEC, CB, ISO9001 |
| Shipping classification | UN 3480 |
| COMMUNICATION METHOD | |
| Vehicle communication mode | CAN |
| Display communication method | RS485 |
PERFORMANCE
Low maintenance
Fast charging
Safest lithium technology
High discharge currents
High capacity
Low Temperature and High Efficiency
