Type: EM2560
Applicable scope: hospital, bank data center, base frame type home, enterprise energy storagebackup power supply, wind complementary system, office, military, base station and other uninterrupted energy storage power supply.
Basic Parameters
Batteries materials: Lithium iron phosphate
Series parallel mode (S series, P parallel): 8S1P
Nominal voltage: 25.6V
Nominal capacity:100Ah
Size（mm）: 475*450(492)*133
Weight: 36kg
Color: Optional
Parallel support: Parallel terminals are supported
Output port mode: terminal
Charging way: CC/CP/VP
Charging current: 0.2C(standard）
Maximum charging current: Max1C @25℃
Charge cut-off voltage: 29.2V/CELL
Discharge way: CC/CP/VP
Discharge current: 0.5C
Maximum discharge current: Max1C @25℃
Discharge cut-off voltage: 22.4V
Charging operating temperature: charging:0~+50℃
Discharge operating temperature: discharge:-20~+55℃
The quality assurance period: 36 months
